Technische Daten
Motor und Akku | |
Motor | Shimano STePS EP600 |
Motorposition | Mitte |
Drehmoment in Nm | 85 Nm |
Akkuposition | voll integriert |
Akku Kapazität | 20 Ah |
Display | Shimano SC-E5003 |
Höchstgeschwindigkeit | 25 km/h |
Antrieb | |
Rücktritt / Freilauf | Freilauf |
Schaltart | Kettenschaltung |
Anzahl Gänge | 12 |
Schaltwerk | Shimano Deore RD-M6100, 12-G |
Schalthebel | Shimano Deore SL-M6100, 12 speed |
Kette / Riemen | Kette |
Kette | KMC e12Turbo, with Quick-Link |
Kasette | Shimano Deore CS-M6100, 12 speed, 11-51T |
Kurbelsatz | Samox for Shimano Steps, 34T chainring |
Pedale | Wellgo, alloy body, ball bearings |
Bremsen | |
Bremsentyp | Scheibenbremse hydraulisch |
Bremse vorne | Shimano MT420/MT410, 4/2-piston hydraulic disc, with 203mm front and 180mm rear rotors |
Bremshebel vorne | Shimano MT4100, 2 finger lever |
Rahmen | |
Rahmenform | Herren |
Rahmen | Hard-tail BESV TRX Series alloy frame, Shimano Steps and internal battery compatible |
Gabel | SR Suntour XCR34, 34mm stanchions, Lockout, Air damping, 1.1/8"-1.5" tapered alloy steerer, travel 120mm |
Komponenten | |
Griffe | E-MTB gel grips with padding and BESV clamp |
Lenker | E-MTB reis bar, 6066 alloy, 4mm rise, sweep: 7 degree back, 31.8mm clamp |
Vorbau | E-MTB 3D Forged alloy stem, 31.8mm clamp, for internal cable routing |
Steuersatz | Acros, AZX-581, 1.5" headset, angular contact bearings, integrated cable routing |
Sattel | Selle Italia Model-X Superflow eBike |
Sattelstütze | Promax SP-726, 31.6mm diameter |
Räder und Naben | |
Radgröße | 29" |
Reifen vorne | Maxxis Ardent, 29"x2.4", Normal Compound, EXO, 60 TPI foldable, Tanwall sides |
Felgen | Formula CL-811 front hub, Formula CL-3248M rear hub, Boost hubs spacing, WTB STi27 29" multichamber alloy rims 32H |
Gewichte | |
zulässiges Gesamtgewicht mit Fahrer und Zuladung | 120 kg |
